红外线光源；
低电压（10-30VDC）；继电器输出；
NPN/PNP，亮通/暗通可选；
具有极性、过载、短路等保护
防护等级：IP67;
直接出线式、接插件式；
工作温度：-25℃至+55℃
产品资料下载| 类型 | 感应模式 | 感应距离 | 感应高度 | 工作电压 | 输出方式 | 尺寸规格 | 外壳材料 | |
|---|---|---|---|---|---|---|---|---|
 |
8条光束 | 20mm | 7m | 140mm | 10-30VDC | NPN/PNP/继电器 | 210*32mm | 铝 |
|
12条光束 | 20mm | 7m | 220mm | 10-30VDC | NPN/PNP/继电器 | 290*32mm | 铝 |
|
16条光束 | 20mm | 7m | 300mm | 10-30VDC | NPN/PNP/继电器 | 370*32mm | 铝 |
|
20条光束 | 20mm | 7m | 380mm | 10-30VDC | NPN/PNP/继电器 | 450*32mm | 铝 |
|
24条光束 | 20mm | 7m | 460mm | 10-30VDC | NPN/PNP/继电器 | 530*32mm | 铝 |
|
28条光束 | 20mm | 7m | 540mm | 10-30VDC | NPN/PNP/继电器 | 610*32mm | 铝 |
|
32条光束 | 20mm | 7m | 620mm | 10-30VDC | NPN/PNP/继电器 | 610*32mm | 铝 |
|
36条光束 | 20mm | 7m | 700mm | 10-30VDC | NPN/PNP/继电器 | 770*32mm | 铝 |
|
40条光束 | 20mm | 7m | 780mm | 10-30VDC | NPN/PNP/继电器 | 850*32mm | 铝 |
|
48条光束 | 20mm | 7m | 860mm | 10-30VDC | NPN/PNP/继电器 | 930*32mm | 铝 |
|
48条光束 | 20mm | 7m | 940mm | 10-30VDC | NPN/PNP/继电器 | 1010*32mm | 铝 |
|
52条光束 | 20mm | 7m | 1020mm | 10-30VDC | NPN/PNP/继电器 | 1090*32mm | 铝 |
|
56条光束 | 20mm | 7m | 1100mm | 10-30VDC | NPN/PNP/继电器 | 1170*32mm | 铝 |
|
60条光束 | 20mm | 7m | 1180mm | 10-30VDC | NPN/PNP/继电器 | 1250*32mm | 铝 |
|
64条光束 | 20mm | 7m | 1260mm | 10-30VDC | NPN/PNP/继电器 | 1330*32mm | 铝 |
|
68条光束 | 20mm | 7m | 1340mm | 10-30VDC | NPN/PNP/继电器 | 1410*32mm | 铝 |
|
72条光束 | 20mm | 7m | 1420mm | 10-30VDC | NPN/PNP/继电器 | 1490*32mm | 铝 |
|
4条光束 | 20/40mm | 7m | 120mm | 10-30VDC | NPN/PNP/继电器 | 210*32mm | 铝 |
|
6条光束 | 20/40mm | 7m | 200mm | 10-30VDC | NPN/PNP/继电器 | 290*32mm | 铝 |
|
8条光束 | 40mm | 7m | 280mm | 10-30VDC | NPN/PNP/继电器 | 370*32mm | 铝 |
|
10条光束 | 40mm | 7m | 360mm | 10-30VDC | NPN/PNP/继电器 | 450*32mm | 铝 |
|
12条光束 | 40mm | 7m | 440mm | 10-30VDC | NPN/PNP/继电器 | 530*32mm | 铝 |
|
14条光束 | 40mm | 7m | 520mm | 10-30VDC | NPN/PNP/继电器 | 610*32mm | 铝 |
|
16条光束 | 40mm | 7m | 600mm | 10-30VDC | NPN/PNP/继电器 | 690*32mm | 铝 |
|
18条光束 | 40mm | 7m | 680mm | 10-30VDC | NPN/PNP/继电器 | 770*32mm | 铝 |
|
20条光束 | 40mm | 7m | 760mm | 10-30VDC | NPN/PNP/继电器 | 850*32mm | 铝 |
|
22条光束 | 40mm | 7m | 840mm | 10-30VDC | NPN/PNP/继电器 | 930*32mm | 铝 |
|
24条光束 | 40mm | 7m | 920mm | 10-30VDC | NPN/PNP/继电器 | 1010*32mm | 铝 |
|
26条光束 | 40mm | 7m | 1000mm | 10-30VDC | NPN/PNP/继电器 | 1090*32mm | 铝 |
|
28条光束 | 40mm | 7m | 1080mm | 10-30VDC | NPN/PNP/继电器 | 1170*32mm | 铝 |
|
30条光束 | 40mm | 7m | 1160mm | 10-30VDC | NPN/PNP/继电器 | 1250*32mm | 铝 |
|
32条光束 | 40mm | 7m | 1240mm | 10-30VDC | NPN/PNP/继电器 | 1330*32mm | 铝 |
|
34条光束 | 40mm | 7m | 1320mm | 10-30VDC | NPN/PNP/继电器 | 1410*32mm | 铝 |
|
36条光束 | 40mm | 7m | 1400mm | 10-30VDC | NPN/PNP/继电器 | 1490*32mm | 铝 |
